Containers & Kubernetes Tutorial

Lab 01 – Run the Pinboard database tier

Table of Contents

Goals

Pre-requisites

Continuity. Pinboard is a three-tier app — web → API → database — and we build it from the bottom up. This lab stands up the database tier only: a postgres:17-alpine container with the notes table that the Pinboard API will read and write from Lab 03 onwards. You are not building any image yet (that is Lab 02) and nothing is wired together yet (that is Lab 03). By the end of this lab the database will be gone — on purpose.

Guide

Step 01: Prepare your working folder and pull the image

All the work you do by hand in this course lives under ~/pinboard-labs/labNN/. Keeping it out of the cloned repo means you can always compare your files with the provided solutions and git pull without conflicts.

mkdir -p ~/pinboard-labs/lab01
cd ~/pinboard-labs/lab01

Pull the database image explicitly, before running anything. docker run would pull it anyway, but doing it separately shows you the layers and the digest.

docker pull postgres:17-alpine

17-alpine: Pulling from library/postgres
9824c27679d3: Pull complete
7c34eb1b1e4d: Pull complete
8f2b9b6f9c95: Pull complete
d0a1c8ba5b1a: Pull complete
Digest: sha256:1f2c5d3a7f8f5a4d2e0e3f5b8a6c9d7e4b2a1c0f9e8d7c6b5a4f3e2d1c0b9a87
Status: Downloaded newer image for postgres:17-alpine
docker.io/library/postgres:17-alpine

That last line is the full name Docker actually used: docker.io/library/postgres:17-alpine — registry / namespace / repository : tag. The Digest: line is the content address of that image: it cannot change, while the tag 17-alpine will point at a new build next month. Pin by digest when you need reproducibility:

DIGEST=$(docker image inspect postgres:17-alpine --format '')
echo "$DIGEST"
docker pull "$DIGEST"

postgres@sha256:1f2c5d3a7f8f5a4d2e0e3f5b8a6c9d7e4b2a1c0f9e8d7c6b5a4f3e2d1c0b9a87
docker.io/library/postgres@sha256:1f2c5d3a7f8f5a4d2e0e3f5b8a6c9d7e4b2a1c0f9e8d7c6b5a4f3e2d1c0b9a87: Pulling from library/postgres
Digest: sha256:1f2c5d3a7f8f5a4d2e0e3f5b8a6c9d7e4b2a1c0f9e8d7c6b5a4f3e2d1c0b9a87
Status: Image is up to date for postgres@sha256:1f2c5d...

Nothing was downloaded — you already have exactly those bytes.

Note. Your digest will be different from the one printed above; images are rebuilt regularly. Always read yours from docker image inspect, never copy one out of a lab sheet.

Step 02: Run Postgres as a container

The official Postgres image is configured only through environment variables. No config file, no installer, no initdb by hand: you pass three variables and the image’s entrypoint bootstraps a cluster on first start.

docker run -d \
  --name pinboard-db \
  -e POSTGRES_USER=pinboard \
  -e POSTGRES_PASSWORD=pinboard-secret \
  -e POSTGRES_DB=pinboard \
  postgres:17-alpine

6b0a2fd4c9e3b1a75f2c8d0e4a6b9c1d3e5f7a8b0c2d4e6f8a0b1c3d5e7f9a2b

The long hex string is the container ID; -d means it runs in the background (“detached”). Check it is up:

docker ps

CONTAINER ID   IMAGE                COMMAND                  CREATED         STATUS         PORTS      NAMES
6b0a2fd4c9e3   postgres:17-alpine   "docker-entrypoint.s…"   8 seconds ago   Up 7 seconds   5432/tcp   pinboard-db

Note. 5432/tcp under PORTS is the port the image declares (EXPOSE), not a published one — there is no -> arrow, so nothing on your host can reach it. That is deliberate: only the Pinboard API needs the database, and from Lab 03 it will reach it over a Docker network. A database on localhost:5432 is a habit worth not forming.

Step 03: Read the logs

A container’s logs are simply whatever PID 1 wrote to stdout/stderr. Docker captures them for you — no log file to find, no journalctl.

docker logs pinboard-db | tail -12

PostgreSQL init process complete; ready for start up.

2026-08-20 09:14:22.184 UTC [1] LOG:  starting PostgreSQL 17.6 on x86_64-pc-linux-musl, compiled by gcc (Alpine 14.2.0) 14.2.0, 64-bit
2026-08-20 09:14:22.185 UTC [1] LOG:  listening on IPv4 address "0.0.0.0", port 5432
2026-08-20 09:14:22.185 UTC [1] LOG:  listening on IPv6 address "::", port 5432
2026-08-20 09:14:22.188 UTC [1] LOG:  listening on Unix socket "/var/run/postgresql/.s.PGSQL.5432"
2026-08-20 09:14:22.190 UTC [1] LOG:  database system was shut down at 2026-08-20 09:14:21 UTC
2026-08-20 09:14:22.194 UTC [1] LOG:  database system is ready to accept connections

database system is ready to accept connections is the line to wait for. Useful variants — try docker logs --tail 5 pinboard-db, docker logs --since 2m pinboard-db, and docker logs -f pinboard-db (follow; Ctrl+C to stop following — it does not stop the container).

Step 04: Create the notes table with docker exec

docker exec starts an extra process inside an already-running container. -it gives it a terminal, exactly like ssh would — except there is no ssh daemon, no extra port and no second user account.

docker exec -it pinboard-db psql -U pinboard -d pinboard

psql (17.6)
Type "help" for help.

pinboard=#

At the pinboard=# prompt, create the table Pinboard uses. This is the same DDL as ~/docker-kubernetes-training/src/db/init.sql (also saved for you as labs/solutions/lab01/notes.sql):

CREATE TABLE IF NOT EXISTS notes (
  id         BIGSERIAL PRIMARY KEY,
  text       TEXT NOT NULL,
  author     TEXT NOT NULL DEFAULT '',
  created_at TIMESTAMPTZ NOT NULL DEFAULT now()
);

CREATE TABLE

Add a few notes:

INSERT INTO notes (text, author) VALUES
  ('A container is just a process with its own view of the system', 'ana'),
  ('Images are layers; containers add a thin writable one on top', 'bruno'),
  ('Hello from init.sql', 'postgres');

INSERT 0 3

Check what you have, then leave psql:

\dt
SELECT id, text, author FROM notes ORDER BY id;
\q

        List of relations
 Schema | Name  | Type  |  Owner
--------+-------+-------+----------
 public | notes | table | pinboard
(1 row)

 id |                             text                              |  author
----+---------------------------------------------------------------+----------
  1 | A container is just a process with its own view of the system | ana
  2 | Images are layers; containers add a thin writable one on top   | bruno
  3 | Hello from init.sql                                            | postgres
(3 rows)

You can also run a single statement without an interactive session — handy in scripts:

docker exec pinboard-db psql -U pinboard -d pinboard -c 'SELECT count(*) FROM notes;'

 count
-------
     3
(1 row)
Check yourself: why is it docker exec here and not docker run? `docker run` always creates a **new container** from an image — a brand-new, freshly-initialised, empty database in this case. `docker exec` runs a command **inside a container that already exists and is running**, so it sees the same filesystem and the same running Postgres server. Rule of thumb: `run` = new container, `exec` = visit a running one, `start` = wake an existing stopped one.

Step 05: Inspect the container with --format

docker inspect prints the container’s complete state and configuration as JSON — several hundred lines. --format (a Go template) picks out just what you need, and is the same syntax you will use in scripts and CI.

docker inspect pinboard-db --format ''
docker inspect pinboard-db --format ''
docker inspect pinboard-db --format ''
docker inspect pinboard-db --format ' → '
docker inspect pinboard-db --format ''

running
2026-08-20T09:14:21.905517293Z
172.17.0.2
postgres:17-alpine → sha256:6c1e5d9a3b2f4c8e7d0a1b2c3d4e5f60718293a4b5c6d7e8f90a1b2c3d4e5f60
POSTGRES_USER=pinboard
POSTGRES_PASSWORD=pinboard-secret
POSTGRES_DB=pinboard
PATH=/usr/local/sbin:/usr/local/bin:/usr/sbin:/usr/bin:/sbin:/bin
PG_MAJOR=17
PG_VERSION=17.6
PGDATA=/var/lib/postgresql/data

Two things to notice:

  1. The container has its own IP (172.17.0.2) on Docker’s default bridge. That is why nothing had to be published for psql inside the container to work.
  2. Your password is in plain text in the container’s configuration, readable by anyone who can run docker inspect, and it will also show up in docker inspect output, in ps output on the host, and in your shell history. Session 08 covers how Kubernetes handles this (and why Secrets are encoded, not encrypted).

Now the interesting one — where does the data actually live?

docker inspect pinboard-db --format '  → '

volume 6f5c4e3d2b1a0f9e8d7c6b5a4f3e2d1c0b9a8f7e6d5c4b3a2f1e0d9c8b7a6f5e → /var/lib/postgresql/data

The Postgres image declares VOLUME /var/lib/postgresql/data in its Dockerfile, so Docker created an anonymous volume with a random name and mounted it there. Keep that name in mind — Step 07 comes back to it.

Step 06: Stop and start — the data survives

docker stop sends SIGTERM to PID 1 and waits (10 s by default) before SIGKILL. Postgres treats SIGTERM as “shut down cleanly”, so this is a real database shutdown, not a power cut.

docker stop pinboard-db
docker ps -a --filter name=pinboard-db

pinboard-db
CONTAINER ID   IMAGE                COMMAND                  CREATED         STATUS                     PORTS     NAMES
6b0a2fd4c9e3   postgres:17-alpine   "docker-entrypoint.s…"   5 minutes ago   Exited (0) 3 seconds ago             pinboard-db

Exited (0) — exit code 0, a clean stop. The container still exists; it is just not running. Note that docker ps alone would not have shown it: you need -a.

docker start pinboard-db
sleep 3
docker exec pinboard-db psql -U pinboard -d pinboard -c 'SELECT count(*) FROM notes;'

pinboard-db
 count
-------
     3
(1 row)

Your three notes are still there. stop/start is not destructive — the container’s filesystem (and its mounted volume) is untouched.

Step 07: Remove the container — the data is gone

Now remove it. -f stops it first if needed.

docker rm -f pinboard-db

pinboard-db

Run a fresh one with exactly the same command as in Step 02, and look for your notes:

docker run -d --name pinboard-db \
  -e POSTGRES_USER=pinboard -e POSTGRES_PASSWORD=pinboard-secret -e POSTGRES_DB=pinboard \
  postgres:17-alpine
sleep 5
docker exec pinboard-db psql -U pinboard -d pinboard -c 'SELECT count(*) FROM notes;'

ERROR:  relation "notes" does not exist
LINE 1: SELECT count(*) FROM notes;
                             ^

The table is gone, the notes are gone. The new container got a new, empty anonymous volume — and the old one is still sitting on your disk with your data in it, orphaned and unreachable:

docker volume ls

DRIVER    VOLUME NAME
local     6f5c4e3d2b1a0f9e8d7c6b5a4f3e2d1c0b9a8f7e6d5c4b3a2f1e0d9c8b7a6f5e
local     b2a1c0f9e8d7c6b5a4f3e2d1c0b9a8f7e6d5c4b3a2f1e0d9c8b7a6f5e4d3c2b1

Warning. This is the single most common beginner accident: docker rm a database container and lose the data, while the disk quietly fills up with anonymous volumes nobody can identify. The fix is to mount a named volume yourself, so that the storage has a name you chose, outlives any container, and can be re-attached to the next one. That is exactly what Lab 03 does with --mount type=volume,src=pinboard-data,... — the notes you pin there will survive docker rm -f pinboard-db.

Check yourself: the container's writable layer survived stop/start in Step 06 but the data still vanished in Step 07. What is the actual rule? Two different storage areas were in play. Anything a container writes goes to its **writable layer**, which is created with the container and **deleted with it** — `stop`/`start` keeps it, `rm` destroys it. But `/var/lib/postgresql/data` was not on the writable layer at all: the image declares a `VOLUME` there, so Docker mounted an anonymous volume. Volumes outlive containers, but an **anonymous** one is bound to the container that created it by name-you-never-saw: the replacement container in Step 07 created its own. Either way the lesson is the same — if you care about the data, name the volume and mount it on purpose.

Remove the second container too; we are done with databases in this lab:

docker rm -f pinboard-db

Step 08: Lifecycle practice with nginx and alpine

Same lifecycle, two very different containers. First a long-running server, with a published port this time (-p HOST:CONTAINER):

docker run -d --name web-demo -p 8080:80 nginx:1.28-alpine
docker ps --filter name=web-demo
curl -s http://localhost:8080 | head -5

CONTAINER ID   IMAGE                COMMAND                   CREATED         STATUS         PORTS                                     NAMES
9d3e1f7a4c02   nginx:1.28-alpine    "/docker-entrypoint.…"    3 seconds ago   Up 2 seconds   0.0.0.0:8080->80/tcp, [::]:8080->80/tcp   web-demo
<!DOCTYPE html>
<html>
<head>
<title>Welcome to nginx!</title>
<style>

Now 0.0.0.0:8080->80/tcp does have an arrow: traffic to port 8080 on your host is forwarded to port 80 inside the container.

Change the page from inside the container — nginx serves files from /usr/share/nginx/html:

docker exec web-demo sh -c 'echo "<h1>Pinboard is coming soon</h1>" > /usr/share/nginx/html/index.html'
curl -s http://localhost:8080

<h1>Pinboard is coming soon</h1>

Note. You just modified the container’s writable layer, not the image. docker run --rm nginx:1.28-alpine would still serve the stock page, and this edit dies with the container. Editing files inside a running container is a debugging move, never a deployment method — Lab 02 bakes changes into an image, Lab 03 mounts them from the host.

Watch the access log you just generated, then stop and remove the container:

docker logs --tail 3 web-demo
docker stop web-demo
docker rm web-demo

172.17.0.1 - - [20/Aug/2026:09:31:02 +0000] "GET / HTTP/1.1" 200 615 "-" "curl/8.5.0" "-"
172.17.0.1 - - [20/Aug/2026:09:31:20 +0000] "GET / HTTP/1.1" 200 33 "-" "curl/8.5.0" "-"
web-demo
web-demo

Now the opposite kind of container: interactive and disposable. -it attaches your terminal, --rm deletes the container the moment you exit.

docker run -it --rm alpine:3.22 sh

Inside it, prove that a container is just an isolated process:

hostname
cat /etc/os-release | head -2
ps -ef
ls /
exit

3f8c1b2d4e6a
NAME="Alpine Linux"
ID=alpine
PID   USER     TIME  COMMAND
    1 root      0:00 sh
    7 root      0:00 ps -ef
bin    dev    etc    home   lib    media  mnt    opt    proc   root   run    sbin   srv    sys    tmp    usr    var

Your shell is PID 1 and it can see exactly two processes — its own PID namespace. Meanwhile on the host, that same shell is an ordinary process (ps -ef | grep sh). The hostname is the container ID. And because of --rm, the container is already gone:

docker ps -a --filter ancestor=alpine:3.22

CONTAINER ID   IMAGE     COMMAND   CREATED   STATUS    PORTS     NAMES

Step 09: Take stock and clean up

List everything, including stopped containers, with a readable format:

docker ps -a --format 'table \t\t'

NAMES     IMAGE     STATUS

Now account for the disk. This is the command to reach for when a lab machine runs out of space:

docker system df

TYPE            TOTAL     ACTIVE    SIZE      RECLAIMABLE
Images          4         0         281.4MB   281.4MB (100%)
Containers      0         0         0B        0B
Local Volumes   2         0         84.2MB    84.2MB (100%)
Build Cache     0         0         0B        0B

Remove stopped containers, then the two orphaned Postgres volumes:

docker container prune -f
docker volume prune -f
docker system df

Total reclaimed space: 0B
Deleted Volumes:
6f5c4e3d2b1a0f9e8d7c6b5a4f3e2d1c0b9a8f7e6d5c4b3a2f1e0d9c8b7a6f5e
b2a1c0f9e8d7c6b5a4f3e2d1c0b9a8f7e6d5c4b3a2f1e0d9c8b7a6f5e4d3c2b1

Total reclaimed space: 84.2MB
TYPE            TOTAL     ACTIVE    SIZE      RECLAIMABLE
Images          4         0         281.4MB   281.4MB (100%)
Containers      0         0         0B        0B
Local Volumes   0         0         0B        0B
Build Cache     0         0         0B        0B

Warning. docker volume prune removes anonymous volumes only, which is safe here. From Lab 03 you will own a named volume called pinboard-data with notes in it — plain prune leaves it alone, but docker volume prune --all and docker system prune --volumes would delete it. Never type either of those on a machine that matters.

Keep your images. Do not run docker image prune -a: postgres:17-alpine, nginx:1.28-alpine and alpine:3.22 are used again in Labs 02–04.

Stretch goal

  1. Let the image create the table for you. Postgres runs any *.sql in /docker-entrypoint-initdb.d/ on first start. Try it with a bind mount:

    docker run -d --name db-init \
  -e POSTGRES_USER=pinboard -e POSTGRES_PASSWORD=pinboard-secret -e POSTGRES_DB=pinboard \
  -v ~/docker-kubernetes-training/src/db/init.sql:/docker-entrypoint-initdb.d/init.sql:ro \
  postgres:17-alpine
sleep 5
docker exec db-init psql -U pinboard -d pinboard -c 'SELECT text, author FROM notes;'
docker rm -f db-init

    Then re-run it against an existing data directory and confirm the script is not executed a second time — a classic production surprise.

  2. Wait properly instead of sleep 5. The image ships pg_isready:

    until docker exec pinboard-db pg_isready -U pinboard -d pinboard -q; do sleep 1; done

    This is the same idea as a container health check (Lab 03) and a Kubernetes readiness probe (Session 06).

  3. Watch resources live. Start the database again and run docker stats in a second terminal while you insert a few thousand rows with INSERT INTO notes (text) SELECT 'note ' || g FROM generate_series(1,5000) g;. Note the memory number — Lab 03 puts a limit on it.

Conclusion

What you have now

State on disk: no containers, no volumes, images only. Pinboard has no database yet, and that is fine: Lab 02 builds the application images, and Lab 03 brings the database back — this time with storage that survives.

Next: Lab 02 – Build the Pinboard images.
